10G/1.25G Symmetric EPON OLT SFP+, 1577/1490nm TX, PR30, 20km SC

This OLT-side optic serves symmetric 10G EPON and legacy 1.25G EPON from one SFP+ cage. Downstream it launches 1577nm at 10.3G and 1490nm at 1.25G; upstream it receives 1270nm at 10.3G and 1310nm at 1.25G. The specification lists ODN class PR30, a 20km reach on single-mode fiber and an SC port, with SFF-8472 diagnostics and IEEE 802.3av compliance. Note: the source title mentions PR40, while the specification table states PR30; we follow the table.

Key Features

• Coexistence of 10G EPON and 1.25G EPON on one OLT port
• TX power +2.0 to +5.0dBm and +2.0 to +7.0dBm for the two downstream channels
• Receiver sensitivity better than -28.0dBm and -29.78dBm
• SC connector, single-mode fiber, 20km
• SFF-8472 diagnostics, IEEE 802.3av
• Commercial, industrial or military temperature grade selectable

Applications

• Central office OLT line cards migrating from EPON to 10G EPON
• FTTH and FTTB access networks
• Mixed ONU populations on one splitter tree

Specifications

Ordering References

Model and part numbers for ordering reference:
