10G/1.25G Asymmetric EPON ONU SFP+, 1310nm TX / 1577nm RX, PRX30

This SFP+ module sits in the subscriber unit of an asymmetric 10G EPON network. It bursts 1.25G upstream at 1310nm and receives 10.3G downstream at 1577nm over single-mode fiber up to 20km. The table lists ODN class PRX30, transmit power of +0.62 to +5.62dBm and sensitivity below -28.5dBm, with an SC port and IEEE 802.3av and SFP+ MSA compliance. The title mentions PR30 and an industrial range, whereas the table gives PRX30 and a selectable grade; please confirm the grade when ordering.

Key Features

• ONU optic, 1.25G up / 10.3G down
• TX 1310nm, RX 1577nm
• TX +0.62 to +5.62dBm; RX < -28.5dBm
• PRX30, 20km, SC
• IEEE 802.3av, SFP+ MSA
• Temperature grade selectable

Applications

• 10G EPON home and business gateways
• SFP+ slot ONUs and stick-style terminals

Specifications

Ordering References

Model and part numbers for ordering reference:
