100GHz 48-Channel Dual-Fiber DWDM Mux/Demux C17-C64 with Monitor and 1310nm Port

Overview

The FT-C17 multiplexes 48 DWDM wavelengths from C17 to C64 onto dual fiber at 100 GHz spacing. Beyond the standard mux and demux function, the unit provides a 1% monitor tap with insertion loss of ≤26 dB and a 1310 nm pass-through port covering 1260 to 1360 nm, allowing legacy traffic or supervisory channels to share the same fiber plant. AAWG technology holds insertion loss at or below 3.5 dB, with center-wavelength accuracy of ±0.05 nm. Packaged in a 1U rack enclosure with LC/UPC connectors, it targets metro transport, data center interconnect links and hybrid networks that carry both DWDM wavelengths and 1310 nm services.

Key Features

• 48 DWDM channels C17-C64, 100 GHz (0.8 nm) spacing
• 1% monitor port (insertion loss ≤26 dB) for in-service monitoring
• 1310 nm pass-through port, 1260-1360 nm, insertion loss ≤0.8 dB
• AAWG Gaussian technology; insertion loss ≤3.5 dB
• Center wavelength accuracy ±0.05 nm
• Isolation adjacent ≥25 dB / non-adjacent ≥29 dB; 1U rack, LC/UPC

Applications

• Metro DWDM transport and aggregation
• Data center interconnect (DCI) links
• Hybrid networks carrying 1310 nm legacy services
• Carrier access and backhaul wavelength expansion

Specifications
