MODEL · FT-575
11-Slot 2RU Packet-Optical Platform (CN)
F-tone Networks Chinese-catalog 11-slot 2RU packet-optical platform in the OTP800 family, ~3.6kg empty, 100W class. Ask Betty or Una for CN chassis pricing.
- Parameter
- FT-P-OTP800-2S
- FT-P-OTP800-4S
- FT-P-OTP800-11S
- Dimensions (Width x Depth x Height)
- Standard 1U Rack Mount (442mmx220mmx44mm)
- Standard 1U Rack Mount (442mmx220mmx44mm)
- Standard 2U Rack Mount (442mmx220mmx88mm)
- Weight (Empty Chassis)
- 2.6 kg
- 2.6 kg
- 3..6 kg
Reference model FT-575 in your inquiry. Datasheets are confirmed offline before order. Full specifications ↓
Specifications
Technical parameters
| Parameter | FT-P-OTP800-2S |
|---|---|
| FT-P-OTP800-4S | FT-P-OTP800-11S |
| Dimensions (Width x Depth x Height) | Standard 1U Rack Mount (442mmx220mmx44mm) |
| Standard 1U Rack Mount (442mmx220mmx44mm) | Standard 2U Rack Mount (442mmx220mmx88mm) |
| Weight (Empty Chassis) | 2.6 kg |
| 2.6 kg | 3..6 kg |
| Power Consumption (Maxi.) | 20W |
| 50W | 100W |
| Rated Current | 0.2A |
| 0.4A | 1A |
| Power Supply | built-in AC220/DC48V(optional) |
| built-in AC220/DC48V(optional) | built-in AC220/DC48V(optional) |
| Slots Note 1 | 2 slots |
| 4 slots | 11 slots |
| Fans | 2-built-in fans | 1 pluggable fan |
| Relative Humidity (Non- condensation) | -10℃～50℃ |
| Storage Temperature | -40℃～85℃ |
| Relative Humidity (Non-condensation) | 5%～95%℃ |
| MTBF | 140127 hours |
| Categories | Part NO. | Description |
| System Control Card | FT-P-OTP800 | 2x100Mbit/s Ethernet ports and 2xSFP module slots |
| OEO card | FT-P-OTP800-OEO(2G5) | 8x42M/622M/1.25G/2.5GE Wavelength Conversion Board |
| FT-P-OTP800-OEO(10G) | 4×10 Gbit/s Wavelength Conversion Board |
| CWDM DWDM TMUX Card | FT-P-OTP800-TMUX (10G) | 8×1.25GE services converged to 1x10G link |
| FT-P-OTP800-TMUX (2G5) | 4×1.25GE services converged to 2×2.5G link with 1+1 protection |
| Optical Line Protection Card | FT-OBP-C | 1:1, 1+1, 1-1 node protection |
| built-in DC48V/220V (optional) | AC220/DC48V 1+1 redundant power |
| Slots | 2 slots |
Overview
Product details
Chinese-catalog twin of the eleven-slot packet-optical chassis. Family table lists the 2U body near 3.6 kg empty and about 100 W max draw with AC220/DC48V 1+1 options. Same OEO, TMUX and OLP card ecosystem as the English listing.
Key Features
- 11-slot 2RU chassis (CN listing)
- Empty weight about 3.6 kg
- Power draw about 100 W class
- AC220/DC48V 1+1 options
- Shared OTP800 card ecosystem
Applications
- CN-catalog metro packet-optical shelves
- OEO/TMUX aggregation chassis
Specifications
| Parameter | Value |
|---|---|
| 4 slots | 11 slots |
| Fans | 2-built-in fans | 1 pluggable fan |
| Storage Temperature | -40℃～85℃ |
| MTBF | 140127 hours |
Ordering References
Model and part numbers for ordering reference:
| Reference | Description |
|---|---|
| FT-P-OTP800 | 2x100Mbit/s Ethernet ports and 2xSFP module slots | System control card P/N |
| FT-P-OTP800-OEO(2G5) | 8x42M/622M/1.25G/2.5GE Wavelength Conversion Board | OEO card P/N |
| 4×10 Gbit/s Wavelength Conversion Board | 10G OEO card description |
| FT-P-OTP800-TMUX (10G) | 8×1.25GE services converged to 1x10G link | TMUX card P/N |
| 4×1.25GE services converged to 2×2.5G link with 1+1 protection | 2.5G TMUX description |
| FT-OBP-C | 1:1, 1+1, 1-1 node protection | OLP card P/N |
Contact Us
For pricing, datasheets and OEM/ODM inquiries, contact the F-tone Networks sales team: betty@f-tone.com / una@f-tone.com · WhatsApp: +86 17360698946 (Betty), +86 17761163895 (Una)
