1-Channel HDMI Fiber Optic Transceiver, 2 km

The FT-339 from F-tone Networks is a 1-channel HDMI fiber optic transceiver kit that extends HDMI video up to 2 km over single-mode. It handles 1920 by 1200 at 60 Hz and 720p, 1080i or 1080p sources with 1.65 Gbps TMDS bandwidth. Alongside video, the pair carries stereo audio and one forward or reverse channel of RS485, RS232 or RS422 data. The fiber port accepts FC, ST, SC or LC connectors and operates at 1310 nm. Each unit runs from 9 to 12 V DC at 5 W maximum and is rated from -25 to +70 °C. Available for standalone or 1U rack mounting, the kit suits conference rooms, broadcast and digital signage links that need lossless long-distance extension.

Key Features

• Transmitter and receiver pair; HDMI carried over single-mode fiber up to 2 km
• 1920 x 1200 at 60 Hz; 720p, 1080i and 1080p sources; 1.65 Gbps TMDS
• Stereo audio plus forward/reverse RS485, RS232 or RS422 data on the same link
• FC, ST, SC or LC fiber port; 1310 nm wavelength
• Transmit power -9.5 to -3 dBm; receiver sensitivity -23 dBm
• 9 to 12 V DC supply, 5 W maximum; -25 to +70 °C; standalone or 1U rack mount

Applications

• Conference rooms and AV installations
• Broadcast and control rooms
• Digital signage with long-distance HDMI extension

For pricing, datasheets and OEM/ODM inquiries, contact the F-tone Networks sales team: una@f-tone.com / betty@f-tone.com · WhatsApp: +86 17761163895
