1 / 21-Channel VGA Fiber Optic Transmitter and Receiver Set
F-tone Networks FT-523: 1-channel VGA fiber transceiver set (Tx/Rx) carries 1080P video, bidirectional audio and RS232/485/422 data over single-mode fiber.
- Video Interface
- Stereo Audio | Fiber Type | Fiber Port | Data Port | Power Supply | Package
- 1 CH VGA
- 1 CH Forward 1 channel reverse 1 channel bidirectional | Single-mode Simplex | FC ST SC LC | 1 channel Forward RS485/RS232/RS422 1 channel reverse RS485/RS232/RS422 1 channel bidirectional RS485/RS232/RS422 | AC110~260V | stand-alone 1U rack mount
- FT3711-T/R
- 1-ch VGA, single fiber
- FT3711A-T/R
- 1-ch VGA, 1-ch bidirectional audio, 1-ch RS232, single fiber
- FT3711B-T/R
- 1-ch VGA, 1-ch bidirectional audio, 1-ch RS232, single fiber
- No.
- 2 (for keyboard and mouse)
Reference model FT-523 in your inquiry. Datasheets are confirmed offline before order. Full specifications ↓
Technical parameters
| Video Interface | Stereo Audio | Fiber Type | Fiber Port | Data Port | Power Supply | Package |
|---|---|
| 1 CH VGA | 1 CH Forward 1 channel reverse 1 channel bidirectional | Single-mode Simplex | FC ST SC LC | 1 channel Forward RS485/RS232/RS422 1 channel reverse RS485/RS232/RS422 1 channel bidirectional RS485/RS232/RS422 | AC110~260V | stand-alone 1U rack mount |
| FT3711-T/R | 1-ch VGA, single fiber |
| FT3711A-T/R | 1-ch VGA, 1-ch bidirectional audio, 1-ch RS232, single fiber |
| FT3711B-T/R | 1-ch VGA, 1-ch bidirectional audio, 1-ch RS232, single fiber |
| No. | 2 (for keyboard and mouse) |
| Video type | RGB with single and sync H,V |
| Input level | 0.7Vp-p |
| Output level | 0.7Vp-p |
| Bandwidth (-3 dB) | 20~20KHz |
| Bit width | 10bit |
| Resolution | Max1080P@60Hz |
| Interface | DB-15 |
| No. of channels | 1-ch bidirectional |
| Input/output level | 5Vp-p,unequilibrium |
| Total harmonic distortion | ≤1% |
| Audio coding | 24bit |
| Input/output impedance | 600Ω or 100KΩ |
| Weighted SNR | ≥90 dB |
| Connector | FC (ST option) |
| Channel | 1-ch duplex |
| Input/output interface? | Terminal block |
| Signal rate | ≥115200bps |
| Signal level | RS232 standard level |
| Wavelength | 1310nm |
| Fiber optic | Single-mode |
| Max. link loss | 12dB（option） |
| Output optical power | 10dBm |
| Receiver sensitivity | ≥20dBm |
| Data Rate | 2.5 |
| Compatibility? | Using PS2 to USB cable, it works fine |
| Freestanding power | 5W |
| Dimension | 237mm * 180mm *28.5mm(high) |
| Power adapter | 220VAC to 12VDC/1A |
| Temperature rage | -40°C to +70°C |
| Relative humidity | < 95% (no condensation) |
Product details
The FT-523 from F-tone Networks is a 1-channel VGA fiber optic transceiver set supplied as a transmitter and receiver pair. It transports VGA video up to 1080P at 60 Hz over a single-mode simplex fiber, and carries one forward, one reverse and one bidirectional serial data channel (RS485/RS232/RS422). The FT3711A and FT3711B versions add one channel of bidirectional stereo audio alongside the video. 10-bit digital sampling with 0.7 Vp-p video levels keeps picture quality stable across the run, and the optical side works at 1310 nm with FC, ST, SC or LC connectors. Rated for -40 to +70 °C, the set suits CCTV control rooms, industrial monitoring and installations that must push analog video between buildings.
Key Features
- Transmitter and receiver pair carrying 1-channel VGA video over single-mode fiber
- Up to 1080P at 60 Hz with 10-bit sampling and 0.7 Vp-p video levels
- Forward, reverse and bidirectional RS485/RS232/RS422 data channels plus 1-channel bidirectional audio
- 1310 nm optical section with FC, ST, SC or LC connector options
- Wide operating range of -40 to +70 °C for industrial environments
- Standalone or 1U rack-mount housing
Applications
- CCTV and video surveillance control rooms
- Industrial monitoring and automation displays
- Campus and building-to-building video links
For pricing, datasheets and OEM/ODM inquiries, contact the F-tone Networks sales team: una@f-tone.com / betty@f-tone.com · WhatsApp: +86 17761163895
