1-Fiber 50/125 um Multimode Seamless Steel Tube Armored Temperature Sensing Cable
F-tone Networks FT-861: 1-fiber 50/125 um multimode temperature sensing cable with stainless steel seamless tube armor for oil, mine and chemical plants.
- Diameter
- Thickness
- Fiber
- mm | 0.25
- Seamless Tube
- 2.30 / 0.20 mm
- 2.30
- 0.20
- Jacket
- mm | 4.00
- Weight
- Kg/km | 20
Reference model FT-861 in your inquiry. Datasheets are confirmed offline before order. Full specifications ↓
Technical parameters
| Diameter | Thickness |
|---|---|
| Fiber | mm | 0.25 |
| Seamless Tube | 2.30 / 0.20 mm |
| 2.30 | 0.20 |
| Jacket | mm | 4.00 |
| Weight | Kg/km | 20 |
| Features Good mechanical properties, transmission performance and environmental performance. Stainless tube protects fibers inside, small diameter and high intensity. Hermetic design of seamless tube ensure good performance of rust resistance and waterproof. LSZH or PVC outer jacket has good performance of flame retardant. | Application Used for temperature and stress measurement Used for tank, mine, chemical and other industries, temperature or pressure measurement, avoid disaster and accidents |
| Package 1 | Package 2 |
| MM 50 | MM 62.5 |
| Core Diameter(µm) | 9.2±0.4 |
| 50±2.5 | 62.5±2.5 |
| Cladding Diameter (µm) | 124.8±0.7 |
| 124.8±0.1 | 124.8±0.1 |
| Cladding Non-circularity(%) | ≤0.7 |
| ≤1.0 | ≤1.0 |
| Core-cladding Concentricity Error (µm) | ≤0.5 |
| ≤1.5 | ≤1.5 |
| Coating Diameter(µm) | 245±5 |
| 245±7 | 245±7 |
| Coarting-cladding Concentricity Error (µm) | ≤12.0 |
| ≤12.0 | ≤12.0 |
| Zero Dispersion Wavelength(nm) | 1302-1322 |
| 1295-1320 | 1320-1365 |
| Zero Dispersion Slop [ps/(nm2.km)] | ≤0.090 |
| ≤0.101 | ≤0.097 |
| Ngroup Index Of Refraction | 1310nm | 1550nm | 850nm | 1300nm | 850nm | 1300nm |
| 1.467 | 1.4677 |
| 1.481 | 1.476 |
| 1.496 | 1.491 |
| Singlemode | Multimode |
| Fiber core/Modal diameter | µm | 9.2±0.4 | 50.0±2.5 | 62.5±2.5 |
| Cladding Diameter | µm | 125.0±1.0 | 125.0±1.0 | 125.0±1.0 |
| Attenuation | dB/km | 0.4dB/km@1310nm | 3.5dB/km@850nm | 3.5dB/km@850nm |
| 0.3dB/km@1550nm | 1.5dB/km@1300nm | 1.5dB/km@1300nm |
| Temperature | ℃ | -20℃~+90℃ |
| Cable Shape | mm | 4.00±0.20 |
| Cable Weight | Kg/km | 20 |
| Allowable Bending Radius | mm | Dynamic 20D Static 10D |
| Allow Tension | N | Long-term 200 Short-term 400 |
| Crush | N | Long-term 800 Short-term 1000 |
Product details
The FT-861 from F-tone Networks is a single-fiber 50/125 um multimode temperature sensing cable armored with a stainless steel seamless tube. The bare fiber is embedded in ointment inside the hermetically sealed tube, which resists rust and water ingress while delivering high tensile and crush resistance in a compact 4.0 mm diameter. An LSZH or PVC flame-retardant outer jacket completes the construction. Rated for -20 to +90 degrees C, the FT-861 is designed for temperature and pressure inspection in oil fields, mines and chemical plants where mechanical robustness and environmental sealing matter.
Key Features
- 1 fiber, 50/125 um multimode
- Stainless steel seamless tube armor, hermetically sealed
- Rust and water resistant tube construction
- LSZH or PVC flame-retardant outer jacket
- Compact 4.0 mm outer diameter; 20 kg/km
- Operating temperature -20 to +90 degrees C
Applications
- Oil field temperature and pressure monitoring
- Mining and chemical plant sensing networks
- Industrial temperature inspection to prevent accidents
- Distributed sensing in harsh environments
For pricing, datasheets and OEM/ODM inquiries, contact the F-tone Networks sales team: una@f-tone.com / betty@f-tone.com · WhatsApp: +86 17761163895
