1 / 2MODEL · FT-519
12F 50/125 MM High-Temp Multicore PTFE Sensor Cable
F-tone Networks 12-fiber 50/125 multimode high-temperature multicore Teflon (PTFE) jacket sensor cable. Ask Betty or Una for PTFE sensor cable pricing.
- Features Has the characteristics of high temperature resistance, can be used in high temperature environment of communication and temperature monitoring. High strength fiber optic cable tensile and compressive properties. Has good environmental adaptation performance, can endure high low temperature difference.
- Application Used for optical fiber temperature sensing system Used for 150 ℃ high temperature environment
- Package 1
- Package 2
- Item
- G652D
- MM 50
- MM 62.5
- Core Diameter(µm)
- 9.2±0.4
- 50±2.5
- 62.5±2.5
Reference model FT-519 in your inquiry. Datasheets are confirmed offline before order. Full specifications ↓
Specifications
Technical parameters
| Features Has the characteristics of high temperature resistance, can be used in high temperature environment of communication and temperature monitoring. High strength fiber optic cable tensile and compressive properties. Has good environmental adaptation performance, can endure high low temperature difference. | Application Used for optical fiber temperature sensing system Used for 150 ℃ high temperature environment |
|---|---|
| Package 1 | Package 2 |
| Item | G652D |
| MM 50 | MM 62.5 |
| Core Diameter(µm) | 9.2±0.4 |
| 50±2.5 | 62.5±2.5 |
| Cladding Diameter (µm) | 124.8±0.7 |
| 124.8±0.1 | 124.8±0.1 |
| Cladding Non-circularity(%) | ≤0.7 |
| ≤1.0 | ≤1.0 |
| Core-cladding Concentricity Error (µm) | ≤0.5 |
| ≤1.5 | ≤1.5 |
| Coating Diameter(µm) | 245±5 |
| 245±7 | 245±7 |
| Coarting-cladding Concentricity Error (µm) | ≤12.0 |
| ≤12.0 | ≤12.0 |
| Zero Dispersion Wavelength(nm) | 1302-1322 |
| 1295-1320 | 1320-1365 |
| Zero Dispersion Slop [ps/(nm2.km)] | ≤0.090 |
| ≤0.101 | ≤0.097 |
| Ngroup Index Of Refraction | 1310nm | 1550nm | 850nm | 1300nm | 850nm | 1300nm |
| 1.467 | 1.4677 |
| 1.481 | 1.476 |
| 1.496 | 1.491 |
| Singlemode | Multimode |
| Fiber core/Modal Diameter | µm | 9.2±0.4 | 50.0±2.5 | 62.5±2.5 |
| Cladding Diameter | µm | 125.0±1.0 | 125.0±1.0 | 125.0±1.0 |
| Attenuation | dB/km | 0.4dB/km@1310nm | 3.5dB/km@850nm | 3.5dB/km@850nm |
| 0.3dB/km@1550nm | 1.5dB/km@1300nm | 1.5dB/km@1300nm |
| Working Temperature | ℃ | -60℃~+85℃ |
| Cable shape | mm | 2.85±0.10 |
| Cable weight | Kg/km | 18 |
| Allowable Bending Radius | mm | Dynamic 20D Static 10D |
| Allow Tension | N | Long-term 200 Short-term 400 |
| Crush | N | Long-term 800 Short-term 1000 |
Overview
Product details
PTFE-jacketed multicore sensor cable keeps twelve 50/125 multimode fibers workable in elevated temperature zones. Source tables mix geometry columns across fiber grades; published text here sticks to the high-temperature PTFE jacket class named in the title.
Key Features
- 12F 50/125 multimode PTFE jacket
- High-temperature sensor cable
- Multicore tight construction
- Teflon (PTFE) outer jacket
- Industrial thermal sensing links
Applications
- High-temperature multimode sensing
- PTFE-jacket industrial fiber runs
Specifications
| Parameter | Value |
|---|---|
| Fiber Core / Modal Diameter | µm | 9.2±0.4 | 50.0±2.5 | 62.5±2.5 |
| Cladding Diameter | µm | 125.0±1.0 | 125.0±1.0 | 125.0±1.0 |
| Attenuation | dB/km | 0.4dB/km@1310nm | 3.5dB/km@850nm | 3.5dB/km@850nm |
| Operating Temperature | ℃ | -60℃~+85℃ |
| Cable Shape | mm | 2.85±0.10 |
| Cable Weight | Kg/km | 18 |
| Allowable Bending Radius | mm | Dynamic 20D Static 10D |
| Allowable Tension | N | Long-term 200 Short-term 400 |
| Crush | N | Long-term 800 Short-term 1000 |
Ordering References
Model and part numbers for ordering reference:
| Reference | Description |
|---|---|
| FT-519 | F-tone part number |
Contact Us
For pricing, datasheets and OEM/ODM inquiries, contact the F-tone Networks sales team: betty@f-tone.com / una@f-tone.com · WhatsApp: +86 17360698946 (Betty), +86 17761163895 (Una)
