10dB Raman Fiber Amplifier, 1530-1562nm

Raman amplification uses the transmission fiber itself as the gain medium, pumping it so signals gain power as they travel. This 10 dB Raman amplifier works over 1530 to 1562 nm and supports 1 to 4 wavelengths with 2 pumps per wavelength. Listed figures include polarization dependent loss of 0.2 dB, polarization mode dispersion of 0.5 ps, -40 dBm output pump leakage and 55 dB return loss on both input and output, with gain flatness of 1 dB on G.652 fiber at 13 dB gain.

Key Features

• Raman gain: 10 dB class
• Operating wavelength: 1530-1562 nm
• 1 to 4 wavelengths, 2 pumps per wavelength
• Polarization dependent loss 0.2 dB; polarization mode dispersion 0.5 ps
• Input and output return loss 55 dB
• Output pump leakage -40 dBm

Applications

• Long-haul and ultra-long-span DWDM links
• Low-noise pre-amplification on G.652 fiber spans

Specifications

Ordering References

Model and part numbers for ordering reference:
