1064nm Polarization Maintaining In-Line Polarizer

Overview

The FT-571 is an in-line polarizer for 1064 nm polarization-maintaining fiber systems. It transmits the wanted polarization with typical insertion loss of 0.4 dB while rejecting the orthogonal state with a typical extinction ratio of 30 dB and minimum 25 dB. Return loss is rated at a minimum of 50 dB, keeping the line clean of stray reflections. Continuous-wave power handling reaches 300 mW, and the device works from -5 to +70 ℃. Pigtail options cover panda, SMF-28e, Hi1060 and related fibers with FC, SC or LC connectors, so the polarizer drops into existing PM assemblies.

Key Features

• 1064 nm PM in-line polarizer with pigtailed package
• Typical extinction ratio 30 dB, minimum 25 dB
• Typical insertion loss 0.4 dB; minimum return loss 50 dB
• 300 mW CW power handling; 5 N maximum tensile load
• Multiple pigtail fiber and FC/SC/LC connector options
• Operating temperature -5 to +70 ℃

Applications

• PM fiber amplifiers
• Coherent communication
• Fiber sensor systems

Specifications
